| XLS 2.2L 6MT 2WD |
 |
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLS 2.2L 6AT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- Ford SYNC® including Radio/CD/MP3; 4" screen; 8 speakers; USB; Aux connector; Bluetooth; voice control
- -
- -
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 2.2 6MT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
- Bodyside LED stop tail lamps
- Bulb daytime running lights (DTRL)
- Door handles - Chrome
- Door mirrors - Chrome
- Exterior mirrors - Power adjust, power fold, heated, puddle lamp, turn indicator & aspherical mirror
- Halogen projector headlamps
- Paint finish roof rails
- Radiator grill - Chrome
- Rain sensing wipers
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- -
- Ford SYNC® 3 including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth and voice control
- Ford SYNC3™ including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth; voice control & navigation
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLS 2.2 6MT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 2.2 6AT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
- Bodyside LED stop tail lamps
- Bulb daytime running lights (DTRL)
- Door handles - Chrome
- Door mirrors - Chrome
- Exterior mirrors - Power adjust, power fold, heated, puddle lamp, turn indicator & aspherical mirror
- Halogen projector headlamps
- Paint finish roof rails
- Radiator grill - Chrome
- Rain sensing wipers
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- -
- Ford SYNC® 3 including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth and voice control
- Ford SYNC3™ including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth; voice control & navigation
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 3.2 6AT 2WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 3.2 6AT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| Limited XLT 3.2 6AT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
next
prev
- XLS 2.2L 6MT 2WD
- XLS 2.2L 6AT 2WD
- XLT 2.2 6MT 2WD
- XLS 2.2 6MT 4WD
- XLT 2.2 6AT 2WD
- XLT 3.2 6AT 2WD
- XLT 3.2 6AT 4WD
- Limited XLT 3.2 6AT 4WD
| XLS 2.2L 6MT 2WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLS 2.2L 6AT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- Ford SYNC® including Radio/CD/MP3; 4" screen; 8 speakers; USB; Aux connector; Bluetooth; voice control
- -
- -
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 2.2 6MT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
- Bodyside LED stop tail lamps
- Bulb daytime running lights (DTRL)
- Door handles - Chrome
- Door mirrors - Chrome
- Exterior mirrors - Power adjust, power fold, heated, puddle lamp, turn indicator & aspherical mirror
- Halogen projector headlamps
- Paint finish roof rails
- Radiator grill - Chrome
- Rain sensing wipers
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- -
- Ford SYNC® 3 including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth and voice control
- Ford SYNC3™ including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth; voice control & navigation
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLS 2.2 6MT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 2.2 6AT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
- Bodyside LED stop tail lamps
- Bulb daytime running lights (DTRL)
- Door handles - Chrome
- Door mirrors - Chrome
- Exterior mirrors - Power adjust, power fold, heated, puddle lamp, turn indicator & aspherical mirror
- Halogen projector headlamps
- Paint finish roof rails
- Radiator grill - Chrome
- Rain sensing wipers
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- -
- Ford SYNC® 3 including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth and voice control
- Ford SYNC3™ including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth; voice control & navigation
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 3.2 6AT 2WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 3.2 6AT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| Limited XLT 3.2 6AT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
next
prev
- XLS 2.2L 6MT 2WD
- XLS 2.2L 6AT 2WD
- XLT 2.2 6MT 2WD
- XLS 2.2 6MT 4WD
- XLT 2.2 6AT 2WD
- XLT 3.2 6AT 2WD
- XLT 3.2 6AT 4WD
- Limited XLT 3.2 6AT 4WD
| XLS 2.2L 6MT 2WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLS 2.2L 6AT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- Ford SYNC® including Radio/CD/MP3; 4" screen; 8 speakers; USB; Aux connector; Bluetooth; voice control
- -
- -
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 2.2 6MT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
- Bodyside LED stop tail lamps
- Bulb daytime running lights (DTRL)
- Door handles - Chrome
- Door mirrors - Chrome
- Exterior mirrors - Power adjust, power fold, heated, puddle lamp, turn indicator & aspherical mirror
- Halogen projector headlamps
- Paint finish roof rails
- Radiator grill - Chrome
- Rain sensing wipers
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- -
- Ford SYNC® 3 including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth and voice control
- Ford SYNC3™ including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth; voice control & navigation
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLS 2.2 6MT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 2.2 6AT 2WD |
|
| Fuel Economy 7.3L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
- Bodyside LED stop tail lamps
- Bulb daytime running lights (DTRL)
- Door handles - Chrome
- Door mirrors - Chrome
- Exterior mirrors - Power adjust, power fold, heated, puddle lamp, turn indicator & aspherical mirror
- Halogen projector headlamps
- Paint finish roof rails
- Radiator grill - Chrome
- Rain sensing wipers
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
In Car Entertainment (ICE)
- -
- Ford SYNC® 3 including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth and voice control
- Ford SYNC3™ including Radio/CD/MP3; 8" touch screen; 10 speakers; x2 USB; Bluetooth; voice control & navigation
- -
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Ratio's Rev : 3.403
- -
- Transmission : Autol
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 3.2 6AT 2WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| XLT 3.2 6AT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
| Limited XLT 3.2 6AT 4WD |
|
| Fuel Economy 6.9L/100km |
| Seating for 7 |
| Book A Test Drive |
.
Dimensions (mm) - Exterior
- Approach angle (kerb) (º) : 29.4
- Departure angle (kerb) (º) : 25
- Front overhang : 905
- Ground clearance : 225
- Overall height : 1837
- Overall length : 4892
- Overall width : 1860
- Ramp breakover angle (kerb) (º) : 21.5
- Rear overhang : 1137
- Wheelbase (mm) : 2850
Dimensions (mm) - Interior
- Effective headroom (mm) (1st / 2nd / 3rd row) : 1017 / 978 / 928
- Effective legroom (mm) (1st / 2nd / 3rd row) : 1058 / 939 / 797
- Hip room (mm) (1st / 2nd / 3rd row) : 1380 / 1384 / 1110
- Seat height (mm) (1st / 2nd / 3rd row) : 300 / 327 / 271
- Shoulder room (mm) (1st / 2nd / 3rd row) : 1440 / 1432 / 1303
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combination Mass (GCM ,Kg) : 5900
- Gross Payload (kg) : 750
- Gross Vehicle Mass [GVM. Kg] : 2900
- Tare (kg) : 2368
- Towing Mass [Braked, (kg)] : 3000
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Bore & Stroke (mm) : 86 x 94.6
- Compression Ratio : 15.7:1
- Cylinders : 4
- Displacement (cm³) : 2198
- Fuel Requirement : Diesel
- Number of Valves : 16
- Power (kW @ rpm) : 118 @ 3700
- Torque: Nm @ rpm : 385 @ 1500-2500
- Type : 2.2
Exterior
- Capped fuel system
- -
- Front bumper - Body colour
- Front fog lights
- Front mud flaps : (Optional)
- Plastic running boards : (Optional)
- Push release mechanism for fuel filler
- Rear bumper - Body colour
- Rear fog lights
- Rear mud flaps
- Rear spoiler
- Tow bar : (Optional)
- Trailer wiring
Ford Protect
- Comprehensive Warranty : 4 yr / 120 000km
- Corrosion Warranty : 5 yr / unlimited km
- Roadside Assistance : 3 yr / unliminted km
- Service Intervals : 15 000 km
- Service Plan : 6 yr / 90 000 km
Instruments & Controls
- Trip computer (distance to empty, instant and average fuel consumption, average speed, outside temperature)
- Washer fluid indicator
- -
- -
Interior - Roof
- Light roof lining with satin grey interior finishes
- Overhead console (contains overhead map lights sunglass holder)
- Sun visor - Front passenger vanity mirror
Occupant Restraints
- Driver & passenger beltminder: Seatbelt warning (only operates if unbuckled)
- Front 3-point seat belts
- Kangaroo pocket for 2nd row buckles
- Two outboard 3-point & one centre 3-point mounted seat belts (2nd row)
- Two outboard 3-point rear seat belts (3rd row)
Safety & Security
- Anti-lock Brake System (ABS)
- Child proof rear door locks
- Curtain airbags
- Driver airbag
- Driver knee airbag : (Optional)
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Emergency Brake Warning
- Front passenger airbag
- Hill Launch Assist (HLA)
- ISOFIX child seat anchorage points (for 2nd row outboard seats only)
- Perimeter burgular alarm system
- Remote entry with selective unlocking & flip key
- Roll Over Mitigation (ROM)
- Seat side airbag
- Trailer Sway Control (TSC)
Seating
- 2nd row 60/40: recline, tip & slide, fold-flat
- 3rd row seat 50/50 fold flat
- 7 seat capacity
- Driver 4-way manual (slide/recline/height) with lumbar support
- Passenger 2-way (slide/recline) manual
Steering
- Electric Power Assist Steering (EPAS) with Drift Compensation Technology
- Turning circle (m)
Suspension
- Front Suspension: Independent with coil spring and anti roll bar
- Rear Suspension: Coil spring with Watt links
Transmission
- Drive Wheels : Rear
- Electronic Locking Rear Differential
- Final Drive : 3.55
- Ratio's 1st : 5.701
- Ratio's 2nd : 2.850
- Ratio's 3rd : 1.645
- Ratio's 4th : 1.183
- Ratio's 5th : 1.000
- Ratio's 6th : 0.814
- Ratio's Rev : 5.170
- -
- Transmission : Manual
- Type : 6-speed
Wheels & Tyres
- Spare Wheel: 17 x 7.5" Steel 265/65/R17
- Wheels: 17 x 8.0" Alloy 265/65/R17 Bridgestone
next
prev
Book A Test Drive
Stay Informed
Find Us
