| 1.5 EcoBoost Trend 6MT FWD |
 |
| Fuel Economy 6.2L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 300mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- -
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 192.9 / 150.8
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 21.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- Front upper grille - silver with chrome bar insert and chrome surround
- -
- -
- Power adjustable, heated mirrors with side indicator. Auto fold (on locking) with approach light (puddle lamps)
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- TFT colour screen trip computer including EcoMode, Shift Indicator, Seatbelt warning
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- Adaptive Cruise Control includes: ASLD (Speed Limiter); Collision Mitigation; Front bumper sensor : opt1*
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- Dual Electronic Air Temperature Control (DEATC)
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- Gearknob - Leather
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- -
- -
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- Active City Stop : Opt1*
- Active Park Assist includes Front Parking sensors and Park Slot Measurement System with Park out assist : opt1*
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- Blind Spot detection system (BLIS) : Opt1*
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- Headlamp jet wash
- Height adjustable seatbelts (front)
- Hill Launch Assist
- Interior mirror - auto dimming
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- Rear parking sensors with audio warning
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- Driver seat lumbar adjust (manual)
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 1.5 EcoBoost Ambiente 6AT FWD |
 |
| Fuel Economy 6.9L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 192.9 / 150.8
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 21.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- TFT colour screen trip computer including EcoMode, Shift Indicator, Seatbelt warning
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 1.5 EcoBoost Ambiente 6MT FWD |
|
| Fuel Economy 6.2L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 2.0 TDCi Trend Powershift 6AT AWD |
|
| Fuel Economy 5.4L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 2.0 TDCi Titanium Powershift 6AT AWD |
 |
| Fuel Economy 5.4L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
next
prev
- 1.5 EcoBoost Trend 6MT FWD
- 1.5 EcoBoost Ambiente 6AT FWD
- 1.5 EcoBoost Ambiente 6MT FWD
- 2.0 TDCi Trend Powershift 6AT AWD
- 2.0 TDCi Titanium Powershift 6AT AWD
| 1.5 EcoBoost Trend 6MT FWD |
|
| Fuel Economy 6.2L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 300mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- -
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 192.9 / 150.8
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 21.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- Front upper grille - silver with chrome bar insert and chrome surround
- -
- -
- Power adjustable, heated mirrors with side indicator. Auto fold (on locking) with approach light (puddle lamps)
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- TFT colour screen trip computer including EcoMode, Shift Indicator, Seatbelt warning
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- Adaptive Cruise Control includes: ASLD (Speed Limiter); Collision Mitigation; Front bumper sensor : opt1*
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- Dual Electronic Air Temperature Control (DEATC)
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- Gearknob - Leather
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- -
- -
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- Active City Stop : Opt1*
- Active Park Assist includes Front Parking sensors and Park Slot Measurement System with Park out assist : opt1*
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- Blind Spot detection system (BLIS) : Opt1*
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- Headlamp jet wash
- Height adjustable seatbelts (front)
- Hill Launch Assist
- Interior mirror - auto dimming
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- Rear parking sensors with audio warning
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- Driver seat lumbar adjust (manual)
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 1.5 EcoBoost Ambiente 6AT FWD |
|
| Fuel Economy 6.9L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 192.9 / 150.8
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 21.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- TFT colour screen trip computer including EcoMode, Shift Indicator, Seatbelt warning
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 1.5 EcoBoost Ambiente 6MT FWD |
|
| Fuel Economy 6.2L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 2.0 TDCi Trend Powershift 6AT AWD |
|
| Fuel Economy 5.4L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 2.0 TDCi Titanium Powershift 6AT AWD |
|
| Fuel Economy 5.4L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
next
prev
- 1.5 EcoBoost Trend 6MT FWD
- 1.5 EcoBoost Ambiente 6AT FWD
- 1.5 EcoBoost Ambiente 6MT FWD
- 2.0 TDCi Trend Powershift 6AT AWD
- 2.0 TDCi Titanium Powershift 6AT AWD
| 1.5 EcoBoost Trend 6MT FWD |
|
| Fuel Economy 6.2L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 300mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- -
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 192.9 / 150.8
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 21.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- Front upper grille - silver with chrome bar insert and chrome surround
- -
- -
- Power adjustable, heated mirrors with side indicator. Auto fold (on locking) with approach light (puddle lamps)
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- TFT colour screen trip computer including EcoMode, Shift Indicator, Seatbelt warning
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- Adaptive Cruise Control includes: ASLD (Speed Limiter); Collision Mitigation; Front bumper sensor : opt1*
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- Dual Electronic Air Temperature Control (DEATC)
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- Gearknob - Leather
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- -
- -
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- Active City Stop : Opt1*
- Active Park Assist includes Front Parking sensors and Park Slot Measurement System with Park out assist : opt1*
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- Blind Spot detection system (BLIS) : Opt1*
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- Headlamp jet wash
- Height adjustable seatbelts (front)
- Hill Launch Assist
- Interior mirror - auto dimming
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- Rear parking sensors with audio warning
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- Driver seat lumbar adjust (manual)
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 1.5 EcoBoost Ambiente 6AT FWD |
|
| Fuel Economy 6.9L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 192.9 / 150.8
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 21.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- TFT colour screen trip computer including EcoMode, Shift Indicator, Seatbelt warning
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 1.5 EcoBoost Ambiente 6MT FWD |
|
| Fuel Economy 6.2L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 2.0 TDCi Trend Powershift 6AT AWD |
|
| Fuel Economy 5.4L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
| 2.0 TDCi Titanium Powershift 6AT AWD |
|
| Fuel Economy 5.4L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Brakes
- Diameter front (mm) : 320mm diameter, 25mm thick
- Diameter rear (mm) : 280mm diameter, 11mm thick
- Electronic parking brake
- Front - Type : Ventilated disc
- Rear - Type : Solid disc
- Manual Hand brake
Dimensions (mm)
- Front overhang : 924
- Front track : 1125
- Ground clearance - Empty / laden to max rear axle load : 197.2 / 123.9
- Headroom - Front / (with panoramic roof option) : 973
- Headroom - Rear / (with panoramic roof option) : 950
- Height (incl. roof rails) : 1703/1694*
- Legroom - Front : 1096
- Legroom - Rear : 934
- Length : 4524
- Max approach angle : 28.2
- Max departure angle : 27.7
- Ramp breakover angle : 17.1
- Rear overhang : 910
- Rear track : 1150
- Shoulder room - Front : 1421
- Shoulder room - Rear : 1398
- Wheelbase : 2690
- Width (excl. mirrors) : 1838
Engine
- Bore (mm) : 79.0
- Compression Ratio : 10.0:1
- Engine Capacity (cc) : 1498
- Engine Type : Inline four cylinder turbo petrol, transverse
- Fuel System : Common-Rail direct injection, turbocharger
- Smart Regenerative Charging
- Stroke (mm) : 81.4
- Auto-Start-Stop
{slier Engine Output}
- Max power (kW @ rpm) : 110 @ 6000
- Max torque (Nm @ rpm) : 240 @ 1600 - 4000
Exterior
- Body colour door handles
- Body colour mirrors
- Body colour roof spoiler
- Body colour upper bumper with self colour lower bumper with silver skid plate - Front & rear
- Bright door frame moulding - Chrome
- Dual tailpipes - Stainless steel finish
- Front fog lamps
- Front lower centre and outer grille - Painted black
- -
- -
- -
- -
- -
- Rear fog lamps
- Roof rails - Silver
- Wheel arch extensions, rocker mouldings, body side skirts - Self colour
- -
- Standard liftgate
In Car Entertainment (ICE)
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touch colour screen and 2 USB port
- Ford SYNC® 3 system with Bluetooth and Voice Control; 8" Touchscreen and navigation (Branded Audio + 9 speakers) : Opt
- Leather Steering wheel mounted audio controls
- Sony audio with 9 speakers
Instruments
- Ambient temperature gauge
- Digital compass
- -
- Trip computer including EcoMode, Shift Indicator and Seatbelt warning
Interior - Comfort & Convenience
- 12V Powerpoint- front and rear -boot
- -
- Centre console with armrest, 2 cup holders and storage bin
- Cruise Control with ASLD (Speed Limiter)
- -
- Flat load floor - Two position (when seats are up or folded flat)
- Ford Power Start button - Keyless start
- Front and rear door trim storage
- Front and rear floor mats
- -
- Manual capless refuelling system
- Overhead console sunglass holder
- Power Point Plug
- Roof mounted grab handles and rear coat hooks
- Storage compartments beneath driver rear footwell
- Storage compartments under rear seats
- Tie downs - Rear compartment - 4 hooks on rear floor
- Tonneau cover
- Air conditioner : Semi-Automatic
- Gearknob - PU
- Lights-on warning alarm
Interior - Lighting
- Cluster variable dimming
- Footwell illumination
- Front and rear courtesy light (LED) with delay
- Map lights - Front and rear
- Rear cargo area illuminated
- Theatre dimming
- Vanity mirror driver & passenger - Illuminatedr
Performance & Economy
- Acceleration 0-100km/h (s) : 9.7
- CO2 emissions (g/km) : 143
- Combined fuel consumption (ℓ / 100km) : 6.2
- Top speed (km/h) : 195
Safety & Security
- -
- -
- Airbags - Side and curtain
- Anti-lock Brake System (ABS)
- Auto "Follow me home" headlamp feature
- Auto headlamp levelling
- -
- Belt minder
- -
- -
- Drive away locking
- Driver knee airbag
- Dual front airbags - driver & passenger
- Electronic Brake Assist (EBA)
- Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with Traction Control
- Engine immobiliser - EPATS system
- -
- Halogen headlamps
- -
- Height adjustable seatbelts (front)
- Hill Launch Assist
- -
- ISOFIX child seat anchors (x2)
- Lane Keeping Aid : Opt1*
- Manual headlamp levelling
- Power child locks
- Power windows - One touch up/down with global open/close
- Privacy glass - Tinted windows
- Rear intermittent wash/wipe
- -
- Rear view camera
- -
- -
- Thatcham Alarm with volume sensing and perimeter alarm
- Trailer Stability function
- Trailer Stability function
- Warning triangle
- Front wipers - Rheostat controlled variable interval intermittent
- Interior mirror - Manual
- Manual "Follow me home" headlamp feature
- Remote central locking
Seating
- 10-way power adjustable driver seat
- 60/40 split rear seats
- 8-way manual adjustable front seat (passenger) with manual lumbar adjust
- Driver seat back pocket
- Leather seats (Torino leather)
- Rear seat centre armrest with cupholders
- Rear seat headrests - Three passengers
- Rear seat recliner (manual)
- Seatback mounted tray tables
- -
- -
- -
- -
- -
Steering
- Electric Power Assisted Steering (EPAS)
- Minimum turning radius (m) : 5.57
- Tilt and telescopic (Rake & Reach) adjustable steering wheel
- Turning circle - Kerb-to-kerb (m) : 11
- Turns lock-to-lock : 2.7
- Type : Rack & pinion
Suspension
- Front axle : Independent MacPherson struts with offset coil spring over gas filled damper units and lower L-arms with optimised front rubber bushings and rear hydro-bush mounted on separate reinforced cross-member sub-frame, anti-roll bar. Dual path top mounts.
- Rear axle: Fully independent multi-link rear axle with control blade with large dampers and rebound springs. Anti roll bar mounted to knuckle via double ball-joint.
- Anti roll bar mounted to knuckle via double ball-joint.
Transmission
- Drive Wheels : AWD: All wheel drive 'Intelligent AWD-System' with variable torque distribution, electronically controlled
- Type : 6-Speed PowerShift Auto with SelectShift
Weight & Capacities
- Fuel tank capacity (ℓ) : 60
- Gross combination mass (kg) : 4330
- Gross vehicle mass (kg) : 2230
- Luggage volume (ℓ) (Rear seatback folded) : 1653
- Luggage volume (ℓ) (Rear seatback up) : 456
- Maximum towing mass (kg) : 1800
next
prev
Book A Test Drive
Stay Informed
Find Us
