| 2.2 TDCi Single Cab Base 5MT 4x2 LR |
 |
| Fuel Economy 9L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 17.3
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 2317
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 17.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4425
- Ground clearance (mm) [Fully loaded] : 135
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1703
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1165
- Ramp break over angle (degrees) : 13.4
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1890
- Towing mass (Braked) (kg) : 1500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1590
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 600
- Wheelbase (mm) : 3220
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- Vinyl Floor covering : O
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Super Cab Base 5MT 4x2 HR |
 |
| Fuel Economy 8.2L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- Power door locks (central locking/unlocking)
- Push - Push release mechanism for fuel filler
- -
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Double Cab Base 5MT 4x2 HR |
 |
| Fuel Economy 8.6L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Plastic console lid material
- -
- Long centre console - Double lid with 2 cupholders & coin storage
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1180
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1875
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- Power door locks (central locking/unlocking)
- Push - Push release mechanism for fuel filler
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Exterior - Trim
- Black Grille
- Outer Door Handles - Black
- Tailgate Handle - Black
- Tailgate Lock
- Rear Mudflaps
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Door Trim
- Door Trim Material - Plastic
- Interior Release Handle - Black
- Vinyl Floor covering : O
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- Two outboard 3-point and one centre 2-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Single Cab XL 6AT 4x2 HR |
 |
| Fuel Economy 7.7L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Plastic console lid material
- -
- Long centre console - Double lid with 2 cupholders & coin storage
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 2317
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1806
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1093
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1962
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Exterior - Trim
- Black Grille
- Outer Door Handles - Black
- Tailgate Handle - Black
- Tailgate Lock
- Rear Mudflaps
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- -
- Reverse : 3.403
- Ratio's 6th : 0.691
- Rear Differential - Locking
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Single Cab XL 6MT 4x2 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 3.15
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- -
- Reverse : 4. 935
- Ratio's 6th : 0. 974
- Rear Differential - Locking
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Single Cab XL 6MT 4x4 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Final Drive : 3.55
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
- Electronic Shift-On-The-Fly (ESOF)
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Super Cab XL 6MT 4x2 HR |
 |
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Final Drive : 3.15
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Super Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
- -
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Super Cab XL 6MT 4x4 HR |
|
| Fuel Economy 7.4L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : 4WD
- Final Drive : 3.55
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
- Electronic Shift-On-The-Fly (ESOF)
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Double Cab XL 6AT 4x2 HR |
 |
| Fuel Economy 7.7L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 999
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 2056
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- ISOFIX seats
- Two outboard 3-point and one centre 3-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- -
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Double Cab XL 6AT 4x2 HR |
|
| Fuel Economy 8.3L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 999
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 2056
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- ISOFIX seats
- Two outboard 3-point and one centre 3-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Descent Control
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
next
prev
- 1. 2.2 TDCi Single Cab Base 5MT 4x2 LR
- 2. 2.2 TDCi Super Cab Base 5MT 4x2 HR
- 3. 2.2 TDCi Double Cab Base 5MT 4x2 HR
- 4. 2.2 TDCi Single Cab XL 6AT 4x2 HR
- 5. 2.2 TDCi Single Cab XL 6MT 4x2 HR
- 6. 2.2 TDCi Single Cab XL 6MT 4x4 HR
- 7. 2.2 TDCi Super Cab XL 6MT 4x2 HR
- 8. 2.2 TDCi Super Cab XL 6AT 4x2 HR
- 9. 2.2 TDCi Super Cab XL 6MT 4x4 HR
- 10. 2.2 TDCi Double Cab XL 6AT 4x2 HR
- 11. 2.2 TDCi Double Cab XL 6AT 4x4 HR
| 2.2 TDCi Single Cab Base 5MT 4x2 LR |
|
| Fuel Economy 9L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 17.3
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 2317
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 17.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4425
- Ground clearance (mm) [Fully loaded] : 135
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1703
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1165
- Ramp break over angle (degrees) : 13.4
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1890
- Towing mass (Braked) (kg) : 1500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1590
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 600
- Wheelbase (mm) : 3220
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- Vinyl Floor covering : O
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Super Cab Base 5MT 4x2 HR |
|
| Fuel Economy 8.2L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- Power door locks (central locking/unlocking)
- Push - Push release mechanism for fuel filler
- -
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Double Cab Base 5MT 4x2 HR |
|
| Fuel Economy 8.6L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Plastic console lid material
- -
- Long centre console - Double lid with 2 cupholders & coin storage
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1180
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1875
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- Power door locks (central locking/unlocking)
- Push - Push release mechanism for fuel filler
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Exterior - Trim
- Black Grille
- Outer Door Handles - Black
- Tailgate Handle - Black
- Tailgate Lock
- Rear Mudflaps
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Door Trim
- Door Trim Material - Plastic
- Interior Release Handle - Black
- Vinyl Floor covering : O
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- Two outboard 3-point and one centre 2-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Single Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Plastic console lid material
- -
- Long centre console - Double lid with 2 cupholders & coin storage
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 2317
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1806
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1093
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1962
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Exterior - Trim
- Black Grille
- Outer Door Handles - Black
- Tailgate Handle - Black
- Tailgate Lock
- Rear Mudflaps
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- -
- Reverse : 3.403
- Ratio's 6th : 0.691
- Rear Differential - Locking
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Single Cab XL 6MT 4x2 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 3.15
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- -
- Reverse : 4. 935
- Ratio's 6th : 0. 974
- Rear Differential - Locking
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Single Cab XL 6MT 4x4 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Final Drive : 3.55
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
- Electronic Shift-On-The-Fly (ESOF)
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Super Cab XL 6MT 4x2 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Final Drive : 3.15
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Super Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
- -
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Super Cab XL 6MT 4x4 HR |
|
| Fuel Economy 7.4L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : 4WD
- Final Drive : 3.55
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
- Electronic Shift-On-The-Fly (ESOF)
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Double Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 999
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 2056
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- ISOFIX seats
- Two outboard 3-point and one centre 3-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- -
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Double Cab XL 6AT 4x2 HR |
|
| Fuel Economy 8.3L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 999
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 2056
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- ISOFIX seats
- Two outboard 3-point and one centre 3-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Descent Control
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
next
prev
- 1. 2.2 TDCi Single Cab Base 5MT 4x2 LR
- 2. 2.2 TDCi Super Cab Base 5MT 4x2 HR
- 3. 2.2 TDCi Double Cab Base 5MT 4x2 HR
- 4. 2.2 TDCi Single Cab XL 6AT 4x2 HR
- 5. 2.2 TDCi Single Cab XL 6MT 4x2 HR
- 6. 2.2 TDCi Single Cab XL 6MT 4x4 HR
- 7. 2.2 TDCi Super Cab XL 6MT 4x2 HR
- 8. 2.2 TDCi Super Cab XL 6AT 4x2 HR
- 9. 2.2 TDCi Super Cab XL 6MT 4x4 HR
- 10. 2.2 TDCi Double Cab XL 6AT 4x2 HR
- 11. 2.2 TDCi Double Cab XL 6AT 4x4 HR
| 2.2 TDCi Single Cab Base 5MT 4x2 LR |
|
| Fuel Economy 9L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 17.3
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 2317
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 17.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4425
- Ground clearance (mm) [Fully loaded] : 135
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1703
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1165
- Ramp break over angle (degrees) : 13.4
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1890
- Towing mass (Braked) (kg) : 1500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1590
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 600
- Wheelbase (mm) : 3220
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- Vinyl Floor covering : O
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Super Cab Base 5MT 4x2 HR |
|
| Fuel Economy 8.2L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- Power door locks (central locking/unlocking)
- Push - Push release mechanism for fuel filler
- -
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Double Cab Base 5MT 4x2 HR |
|
| Fuel Economy 8.6L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Plastic console lid material
- -
- Long centre console - Double lid with 2 cupholders & coin storage
Chassis & Brake System
- Front Disc Brakes & Rear Drum Brakes
- Hydraulic Power Assisted Steering (HPAS)
- Standard Drive Shaft
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1180
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1875
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- Power door locks (central locking/unlocking)
- Push - Push release mechanism for fuel filler
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 285 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- Exterior Mirrors- Manual adjust
Exterior - Trim
- Black Grille
- Outer Door Handles - Black
- Tailgate Handle - Black
- Tailgate Lock
- Rear Mudflaps
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Door Trim
- Door Trim Material - Plastic
- Interior Release Handle - Black
- Vinyl Floor covering : O
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- Two outboard 3-point and one centre 2-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 4.7
- Ratio's 1st : 4. 220
- Ratio's 2nd : 2. 238
- Ratio's 3rd : 1. 366
- Ratio's 4th : 1. 000
- Ratio's 5th : 0. 763
- Rear Differential - Open
- Reverse : 3. 84
| 2.2 TDCi Single Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Plastic console lid material
- -
- Long centre console - Double lid with 2 cupholders & coin storage
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 2317
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1806
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1093
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1962
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Exterior - Trim
- Black Grille
- Outer Door Handles - Black
- Tailgate Handle - Black
- Tailgate Lock
- Rear Mudflaps
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- -
- Reverse : 3.403
- Ratio's 6th : 0.691
- Rear Differential - Locking
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Single Cab XL 6MT 4x2 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Drive Wheels : Rear
- Final Drive : 3.15
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- -
- Reverse : 4. 935
- Ratio's 6th : 0. 974
- Rear Differential - Locking
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Single Cab XL 6MT 4x4 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Transmission
- Final Drive : 3.55
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
- Electronic Shift-On-The-Fly (ESOF)
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Super Cab XL 6MT 4x2 HR |
|
| Fuel Economy 6.8L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Final Drive : 3.15
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Super Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
- -
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
| 2.2 TDCi Super Cab XL 6MT 4x4 HR |
|
| Fuel Economy 7.4L/100km |
| Seating for 2 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1847
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 4800
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 2925
- Overall height (mm) : 1810
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 1300
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 1480
- Towing mass (Braked) (kg) : 2500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- -
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : 4WD
- Final Drive : 3.55
- Ratio's 1st : 5. 441
- Ratio's 2nd : 2. 839
- Ratio's 3rd : 1. 721
- Ratio's 4th : 1. 223
- Ratio's 5th : 1. 000
- Ratio's 6th : 0. 974
- Rear Differential - Locking
- Reverse : 4. 935
- Electronic Shift-On-The-Fly (ESOF)
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Launch Assist
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Double Cab XL 6AT 4x2 HR |
|
| Fuel Economy 7.7L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 999
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 2056
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- ISOFIX seats
- Two outboard 3-point and one centre 3-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- -
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
| 2.2 TDCi Double Cab XL 6AT 4x2 HR |
|
| Fuel Economy 8.3L/100km |
| Seating for 5 |
| Book A Test Drive |
.
Centre Console
- Long centre console - Double lid with 2 cupholders & coin storage
- Plastic console lid material
- -
Dimensions & Weights
- Approach angle (degrees) : 25.5
- Cargo depth (mm) : 511
- Cargo floor length (mm) : 1549
- Cargo floor width (mm) : 1560
- Cargo width (mm) [between wheel arches] : 1139
- Departure angle (degrees) : 21.8
- Front Overhang (mm) : 905
- Fuel capacity (Litres) : 80
- GCM (Gross Combination Mass) (kg) : 6000
- Ground clearance (mm) [Fully loaded] : 237
- GVM (Gross Vehicle Mass) (kg) : 3200
- Overall height (mm) : 1851
- Overall length (mm) : 5354
- Overall width (excl. outer mirror) (mm) : 1860
- Overall width (incl. outer mirror) (mm) : 2163
- Payload (kg) [passenger weight (65kg) and fuel weight (80l) removed] : 999
- Ramp break over angle (degrees) : 18.5
- Rear Overhang (mm) : 1226
- Tare Mass (kg) : 2056
- Towing mass (Braked) (kg) : 3500
- Towing mass (Unbraked) (kg) : 750
- Track (mm) : 1560
- Turning circle (Kerb to kerb) (m) : 12.7
- Wading depth (mm) : 800
- Wheelbase (mm) : 3220
Door Locking
- -
- -
- -
- -
- -
- Push - Push release mechanism for fuel filler
- Power Double Locking
- Remote control entry with 2-stage unlocking and flip key
- Child proof rear door locks
Engine
- Bore x stroke (mm) : 86x94.6
- Compression Ratio : 15,7:1
- Engine Displacement (cc) : 2198
- Fuel Requirement : Diesel
- No. of cylinders : 4
- Number of Valves : 16
- Power (kW @ rpm) : 88 @ 3700
- Torque (Nm @ rpm) : 385 @ 1500-2300
Exterior - Lighting
- Halogen headlamps with headlights off with ignition off
- Indicators - Side repeaters on body
- Reflector headlamps
- Daytime Running Lights
- Manual Front Headlamp Leveling
Exterior - Mirrors (Driver & Front Passenger)
- Exterior Mirror Finish-Black
- -
- Exterior Mirrors- Power adjust, Manual Fold
Front Seats
- 2 way manual adjustment (driver bucket seat)
- -
- 2 Separate Bucket Seats - driver & passenger
Instrument Panel, Cockpit & Controls
- 12V power point plug - Front console
- 12V power point plug - Rear console
Interior - Floor & Cowl Side Trim
- Drivers only front floor mat (Standard with carpet flooring)
- Nonwoven fabric Carpet
- -
Interior - Roof Trim
- -
- -
- Roof mounted grab handle
- Sun Visor - Driver with ticket holder
- Sun Visor - Front Passenger with vanity mirror
Rear Seats
- Rear Seat Outboard Head Restraints with Rear Centre Head Restraint
- Second Row Bench Seat (3 Passengers)
Safety/Restraints
- Driver Airbag : O*
- Driver Belt minder : O*
- Front Passenger Airbag : O*
- Seat Belt Pre-tensioners : O*
- ISOFIX seats
- Two outboard 3-point and one centre 3-point rear seat belts
Service & Warranty
- Corrosion Warranty (5 years / unlimited km's)
- Roadside assistance (3 years / unlimited km's)
- Service Intervals (15 000 km)
- Service Plan (6 years / 90 000 km)
- Warranty (4 years / 120 000km)
Stowage
- -
- -
- -
- -
- Overhead Console contains overhead map lights, sunglass holder and Overhead Dome Lamp
- Rear box storage
Transmission
- Drive Wheels : Rear
- Final Drive : 3.73
- Ratio's 1st : 4.171
- Ratio's 2nd : 2.312
- Ratio's 3rd : 1.521
- Ratio's 4th : 1.143
- Ratio's 5th : 0.867
- Ratio's 6th : 0.691
- Rear Differential - Locking
- Reverse : 3.403
Vehicle Capabilities
- ABS with Electronic brakeforce distribution (EBD) : O
- Front towing hook
- Adaptive Load Control
- Electronic Stability Programme (ESP)
- ESP Brake System
- Hill Descent Control
- Roll-Over Mitigation
- Tow bar
- Traction Control
- Trailer Sway Control
- Hill Descent Control
next
prev
Book A Test Drive
Stay Informed
Find Us
