| 2.2TDCI MWB CHASSIS CAB 6MT WITH FLOAT |
 |
| Fuel Economy 7.6L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 3142
- Floor/Chassis frame height (fwd/rwd) : 737
- Front overhang : 1023
- Front track : 1732
- Overall height (fwd/rwd) : 2176
- Overall length (w/o float) : 5572
- Overall length (w float) : 5767
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2098
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2097
- Rear over hang : 1240
- Rear track (SRW) : 1743
- Turning circle (kerb-to-kerb) (m) : 12.5
- Wheel base : 3504
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 5000
- Gross Payload (kg) : 1597
- Gross Vehicle Mass [GVM. Kg] : 3300
- Kerb weight (kg) : 1628
- Towing Mass [Braked, (kg)] : 2800
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 92kW
- Torque: Nm @ rpm : 350Nm
- Type : Duratorq TDCi 2.2
Exterior
- Clear turn indicators
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- -
- -
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.71
- Ratio's 1st : 3.727
- Ratio's 2nd : 1.864
- Ratio's 3rd : 1.121
- Ratio's 4th : 0.780
- Ratio's 5th : 0.844
- Ratio's 6th : 0.683
- Ratio's Rev : -5.303521
- Type : 6-speed manual
| 2.2TDCI ELWB CHASSIS CAB 6MT WITH FLOAT |
 |
| Fuel Economy 9.3L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 4149
- Floor/Chassis frame height (fwd/rwd) : 743
- Front overhang : 1023
- Front track : 1740
- Overall height (fwd/rwd) : 2183
- Overall length (w/o float) : 6579
- Overall length (w float) : 6797
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2198
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2547
- Rear over hang : 1820
- -
- Turning circle (kerb-to-kerb) (m) : 13.3
- Wheel base : 3954
- Rear track (DRW) : 1670
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 7000
- Gross Payload (kg) : 2691
- Gross Vehicle Mass [GVM. Kg] : 4700
- Kerb weight (kg) : 1934
- Towing Mass [Braked, (kg)] : 3500
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 114kW
- Torque: Nm @ rpm : 385Nm
- Type : Duratorq TDCi 2.2
Exterior
- -
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- Orange turn indicators
- Roof mounted light
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.10
- Ratio's 1st : 5.441
- Ratio's 2nd : 2.839
- Ratio's 3rd : 1.721
- Ratio's 4th : 1.223
- Ratio's 5th : 1.000
- Ratio's 6th : 0.794
- Ratio's Rev : -4.935
- Type : 6-speed manual
Wheels & Tyres
- -
- Non-locking wheel nuts
- Spare wheel
- (Dual Rear Wheel) - 195/75 R16C 107/105 - Steel
- Hub caps
| 2.2TDCI MWB CHASSIS CAB 6MT WITHOUT FLOAT |
 |
| Fuel Economy 7.6L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 3142
- Floor/Chassis frame height (fwd/rwd) : 737
- Front overhang : 1023
- Front track : 1732
- Overall height (fwd/rwd) : 2176
- Overall length (w/o float) : 5572
- Overall length (w float) : 5767
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2098
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2097
- Rear over hang : 1240
- Rear track (SRW) : 1743
- Turning circle (kerb-to-kerb) (m) : 12.5
- Wheel base : 3504
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 5000
- Gross Payload (kg) : 1597
- Gross Vehicle Mass [GVM. Kg] : 3300
- Kerb weight (kg) : 1628
- Towing Mass [Braked, (kg)] : 2800
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 92kW
- Torque: Nm @ rpm : 350Nm
- Type : Duratorq TDCi 2.2
Exterior
- Clear turn indicators
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- -
- -
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.71
- Ratio's 1st : 3.727
- Ratio's 2nd : 1.864
- Ratio's 3rd : 1.121
- Ratio's 4th : 0.780
- Ratio's 5th : 0.844
- Ratio's 6th : 0.683
- Ratio's Rev : -5.303521
- Type : 6-speed manual
| 2.2TDCI ELWB CHASSIS CAB 6MT WITHOUT FLOAT |
|
| Fuel Economy 9.3L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 4149
- Floor/Chassis frame height (fwd/rwd) : 743
- Front overhang : 1023
- Front track : 1740
- Overall height (fwd/rwd) : 2183
- Overall length (w/o float) : 6579
- Overall length (w float) : 6797
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2198
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2547
- Rear over hang : 1820
- -
- Turning circle (kerb-to-kerb) (m) : 13.3
- Wheel base : 3954
- Rear track (DRW) : 1670
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 7000
- Gross Payload (kg) : 2691
- Gross Vehicle Mass [GVM. Kg] : 4700
- Kerb weight (kg) : 1934
- Towing Mass [Braked, (kg)] : 3500
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 114kW
- Torque: Nm @ rpm : 385Nm
- Type : Duratorq TDCi 2.2
Exterior
- -
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- Orange turn indicators
- Roof mounted light
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.10
- Ratio's 1st : 5.441
- Ratio's 2nd : 2.839
- Ratio's 3rd : 1.721
- Ratio's 4th : 1.223
- Ratio's 5th : 1.000
- Ratio's 6th : 0.794
- Ratio's Rev : -4.935
- Type : 6-speed manual
Wheels & Tyres
- -
- Non-locking wheel nuts
- Spare wheel
- (Dual Rear Wheel) - 195/75 R16C 107/105 - Steel
- Hub caps
next
prev
- 2.2TDCI MWB CHASSIS CAB 6MT WITH FLOAT
- 2.2TDCI ELWB CHASSIS CAB 6MT WITH FLOAT
- 2.2TDCI MWB CHASSIS CAB 6MT WITHOUT FLOAT
- 2.2TDCI ELWB CHASSIS CAB 6MT WITHOUT FLOAT
| 2.2TDCI MWB CHASSIS CAB 6MT WITH FLOAT |
|
| Fuel Economy 7.6L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 3142
- Floor/Chassis frame height (fwd/rwd) : 737
- Front overhang : 1023
- Front track : 1732
- Overall height (fwd/rwd) : 2176
- Overall length (w/o float) : 5572
- Overall length (w float) : 5767
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2098
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2097
- Rear over hang : 1240
- Rear track (SRW) : 1743
- Turning circle (kerb-to-kerb) (m) : 12.5
- Wheel base : 3504
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 5000
- Gross Payload (kg) : 1597
- Gross Vehicle Mass [GVM. Kg] : 3300
- Kerb weight (kg) : 1628
- Towing Mass [Braked, (kg)] : 2800
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 92kW
- Torque: Nm @ rpm : 350Nm
- Type : Duratorq TDCi 2.2
Exterior
- Clear turn indicators
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- -
- -
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.71
- Ratio's 1st : 3.727
- Ratio's 2nd : 1.864
- Ratio's 3rd : 1.121
- Ratio's 4th : 0.780
- Ratio's 5th : 0.844
- Ratio's 6th : 0.683
- Ratio's Rev : -5.303521
- Type : 6-speed manual
| 2.2TDCI ELWB CHASSIS CAB 6MT WITH FLOAT |
|
| Fuel Economy 9.3L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 4149
- Floor/Chassis frame height (fwd/rwd) : 743
- Front overhang : 1023
- Front track : 1740
- Overall height (fwd/rwd) : 2183
- Overall length (w/o float) : 6579
- Overall length (w float) : 6797
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2198
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2547
- Rear over hang : 1820
- -
- Turning circle (kerb-to-kerb) (m) : 13.3
- Wheel base : 3954
- Rear track (DRW) : 1670
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 7000
- Gross Payload (kg) : 2691
- Gross Vehicle Mass [GVM. Kg] : 4700
- Kerb weight (kg) : 1934
- Towing Mass [Braked, (kg)] : 3500
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 114kW
- Torque: Nm @ rpm : 385Nm
- Type : Duratorq TDCi 2.2
Exterior
- -
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- Orange turn indicators
- Roof mounted light
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.10
- Ratio's 1st : 5.441
- Ratio's 2nd : 2.839
- Ratio's 3rd : 1.721
- Ratio's 4th : 1.223
- Ratio's 5th : 1.000
- Ratio's 6th : 0.794
- Ratio's Rev : -4.935
- Type : 6-speed manual
Wheels & Tyres
- -
- Non-locking wheel nuts
- Spare wheel
- (Dual Rear Wheel) - 195/75 R16C 107/105 - Steel
- Hub caps
| 2.2TDCI MWB CHASSIS CAB 6MT WITHOUT FLOAT |
|
| Fuel Economy 7.6L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 3142
- Floor/Chassis frame height (fwd/rwd) : 737
- Front overhang : 1023
- Front track : 1732
- Overall height (fwd/rwd) : 2176
- Overall length (w/o float) : 5572
- Overall length (w float) : 5767
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2098
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2097
- Rear over hang : 1240
- Rear track (SRW) : 1743
- Turning circle (kerb-to-kerb) (m) : 12.5
- Wheel base : 3504
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 5000
- Gross Payload (kg) : 1597
- Gross Vehicle Mass [GVM. Kg] : 3300
- Kerb weight (kg) : 1628
- Towing Mass [Braked, (kg)] : 2800
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 92kW
- Torque: Nm @ rpm : 350Nm
- Type : Duratorq TDCi 2.2
Exterior
- Clear turn indicators
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- -
- -
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.71
- Ratio's 1st : 3.727
- Ratio's 2nd : 1.864
- Ratio's 3rd : 1.121
- Ratio's 4th : 0.780
- Ratio's 5th : 0.844
- Ratio's 6th : 0.683
- Ratio's Rev : -5.303521
- Type : 6-speed manual
| 2.2TDCI ELWB CHASSIS CAB 6MT WITHOUT FLOAT |
|
| Fuel Economy 9.3L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 4149
- Floor/Chassis frame height (fwd/rwd) : 743
- Front overhang : 1023
- Front track : 1740
- Overall height (fwd/rwd) : 2183
- Overall length (w/o float) : 6579
- Overall length (w float) : 6797
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2198
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2547
- Rear over hang : 1820
- -
- Turning circle (kerb-to-kerb) (m) : 13.3
- Wheel base : 3954
- Rear track (DRW) : 1670
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 7000
- Gross Payload (kg) : 2691
- Gross Vehicle Mass [GVM. Kg] : 4700
- Kerb weight (kg) : 1934
- Towing Mass [Braked, (kg)] : 3500
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 114kW
- Torque: Nm @ rpm : 385Nm
- Type : Duratorq TDCi 2.2
Exterior
- -
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- Orange turn indicators
- Roof mounted light
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.10
- Ratio's 1st : 5.441
- Ratio's 2nd : 2.839
- Ratio's 3rd : 1.721
- Ratio's 4th : 1.223
- Ratio's 5th : 1.000
- Ratio's 6th : 0.794
- Ratio's Rev : -4.935
- Type : 6-speed manual
Wheels & Tyres
- -
- Non-locking wheel nuts
- Spare wheel
- (Dual Rear Wheel) - 195/75 R16C 107/105 - Steel
- Hub caps
next
prev
- 2.2TDCI MWB CHASSIS CAB 6MT WITH FLOAT
- 2.2TDCI ELWB CHASSIS CAB 6MT WITH FLOAT
- 2.2TDCI MWB CHASSIS CAB 6MT WITHOUT FLOAT
- 2.2TDCI ELWB CHASSIS CAB 6MT WITHOUT FLOAT
| 2.2TDCI MWB CHASSIS CAB 6MT WITH FLOAT |
|
| Fuel Economy 7.6L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 3142
- Floor/Chassis frame height (fwd/rwd) : 737
- Front overhang : 1023
- Front track : 1732
- Overall height (fwd/rwd) : 2176
- Overall length (w/o float) : 5572
- Overall length (w float) : 5767
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2098
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2097
- Rear over hang : 1240
- Rear track (SRW) : 1743
- Turning circle (kerb-to-kerb) (m) : 12.5
- Wheel base : 3504
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 5000
- Gross Payload (kg) : 1597
- Gross Vehicle Mass [GVM. Kg] : 3300
- Kerb weight (kg) : 1628
- Towing Mass [Braked, (kg)] : 2800
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 92kW
- Torque: Nm @ rpm : 350Nm
- Type : Duratorq TDCi 2.2
Exterior
- Clear turn indicators
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- -
- -
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.71
- Ratio's 1st : 3.727
- Ratio's 2nd : 1.864
- Ratio's 3rd : 1.121
- Ratio's 4th : 0.780
- Ratio's 5th : 0.844
- Ratio's 6th : 0.683
- Ratio's Rev : -5.303521
- Type : 6-speed manual
| 2.2TDCI ELWB CHASSIS CAB 6MT WITH FLOAT |
|
| Fuel Economy 9.3L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 4149
- Floor/Chassis frame height (fwd/rwd) : 743
- Front overhang : 1023
- Front track : 1740
- Overall height (fwd/rwd) : 2183
- Overall length (w/o float) : 6579
- Overall length (w float) : 6797
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2198
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2547
- Rear over hang : 1820
- -
- Turning circle (kerb-to-kerb) (m) : 13.3
- Wheel base : 3954
- Rear track (DRW) : 1670
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 7000
- Gross Payload (kg) : 2691
- Gross Vehicle Mass [GVM. Kg] : 4700
- Kerb weight (kg) : 1934
- Towing Mass [Braked, (kg)] : 3500
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 114kW
- Torque: Nm @ rpm : 385Nm
- Type : Duratorq TDCi 2.2
Exterior
- -
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- Orange turn indicators
- Roof mounted light
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.10
- Ratio's 1st : 5.441
- Ratio's 2nd : 2.839
- Ratio's 3rd : 1.721
- Ratio's 4th : 1.223
- Ratio's 5th : 1.000
- Ratio's 6th : 0.794
- Ratio's Rev : -4.935
- Type : 6-speed manual
Wheels & Tyres
- -
- Non-locking wheel nuts
- Spare wheel
- (Dual Rear Wheel) - 195/75 R16C 107/105 - Steel
- Hub caps
| 2.2TDCI MWB CHASSIS CAB 6MT WITHOUT FLOAT |
|
| Fuel Economy 7.6L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 3142
- Floor/Chassis frame height (fwd/rwd) : 737
- Front overhang : 1023
- Front track : 1732
- Overall height (fwd/rwd) : 2176
- Overall length (w/o float) : 5572
- Overall length (w float) : 5767
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2098
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2097
- Rear over hang : 1240
- Rear track (SRW) : 1743
- Turning circle (kerb-to-kerb) (m) : 12.5
- Wheel base : 3504
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 5000
- Gross Payload (kg) : 1597
- Gross Vehicle Mass [GVM. Kg] : 3300
- Kerb weight (kg) : 1628
- Towing Mass [Braked, (kg)] : 2800
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 92kW
- Torque: Nm @ rpm : 350Nm
- Type : Duratorq TDCi 2.2
Exterior
- Clear turn indicators
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- -
- -
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.71
- Ratio's 1st : 3.727
- Ratio's 2nd : 1.864
- Ratio's 3rd : 1.121
- Ratio's 4th : 0.780
- Ratio's 5th : 0.844
- Ratio's 6th : 0.683
- Ratio's Rev : -5.303521
- Type : 6-speed manual
| 2.2TDCI ELWB CHASSIS CAB 6MT WITHOUT FLOAT |
|
| Fuel Economy 9.3L/100km |
| Seating for 3 |
| Book A Test Drive |
.
Brakes
- ABS with Electronic Brake-force Distribution (EBD)
- Electronic Stability Programme (ESP) with failed boost support
- Emergency Brake Assist (EBA)
- Emergency brake warning
- Front ventilated discs
- Rear solid discs
Dimensions (mm) - Exterior
- Chassis frame length : 4149
- Floor/Chassis frame height (fwd/rwd) : 743
- Front overhang : 1023
- Front track : 1740
- Overall height (fwd/rwd) : 2183
- Overall length (w/o float) : 6579
- Overall length (w float) : 6797
- Overall width (w/o float) DRW no mirrors : 2052
- Overall width (w/o float) DRW with mirrors : 2474
- Overall width (w float) SRW/DRW no mirrors : 2198
- Rear of cab to front wheel centre : 1407
- Rear of cab to rear wheel centre : 2547
- Rear over hang : 1820
- -
- Turning circle (kerb-to-kerb) (m) : 13.3
- Wheel base : 3954
- Rear track (DRW) : 1670
Dimensions - Other
- Fuel Tank (ℓ) : 80
- Gross Combined Mass (GCM) (kg) : 7000
- Gross Payload (kg) : 2691
- Gross Vehicle Mass [GVM. Kg] : 4700
- Kerb weight (kg) : 1934
- Towing Mass [Braked, (kg)] : 3500
- Towing Mass [Unbraked, (kg)] : 750
Engine
- Cylinders : 4 in line
- Diesel particulate filter
- Displacement (cm³) : 2198
- Fuel filler neck without misfuel inhibit
- Fuel Requirement : Diesel
- Power (kW @ rpm) : 114kW
- Torque: Nm @ rpm : 385Nm
- Type : Duratorq TDCi 2.2
Exterior
- -
- Door handles - Self colour (black)
- Dual heated powerfold side mirrors
- Front bumper – Partial body colour
- Grille - Self colour
- Rear bumper underrun bar
- Rear mud flaps
- Short arm mirrors
- Side marker lamps
- Wipers – Front, variable/intermittent with electric wash
- Orange turn indicators
- Roof mounted light
Exterior - Lighting
- Follow-me-home lighting
- Headlights – Projector-style halogen reflector lights (Quad Beam)
- Manual headlamp levelling
Ford Protect
- Comprehensive Warranty : 4 yr/120 000km
- Corrosion Warranty : 5 yr/unlimited km
- Roadside Assistance : 3 yr/unlimited km
- Service Intervals : 15 000km
- Service Plan : Dealer Option
In Car Entertainment (ICE)
- Ice Pack 2
- Radio
- USB
- Bluetooth
- 2 Front speakers + 2 tweeters
- Single AM/FM antenna
- Radio controls on steering wheel
- Aux input jack
- Microphone
- Roof mounted antenna + speaker wiring
Interiors
- 2x 12V connections
- Base level interior trim accent pack
- Centre console with 2 x cupholders
- Glovebox
Interior - Roof
- Driver and passenger sunvisor
- Header mounted open package tray
- Overhead console - front
Options - Available at an extra cost
- Chassis Option 1 Standard Aluminum wide float
- Chassis Option 2 Comfort Pack: Front manual airconditioner + front passenger airbag
Safety & Security
- Anti-lock Brake System (ABS)
- Door auto-relocking enabled - (45 seconds conditional)
- Door entry remote-multi channel - (rechargeable - (1 fob + 1 plain key)
- Drive Away Locking with Crash Unlocking
- Driver airbag
- Electronic Brakeforce Distribution (EBD)
- Electronic Stability Programme (ESP)
- Hill Launch Assist (HLA)
- Perimeter Anti-Theft Alarm
- Power door dead locks - shielded
- Roll Over Mitigation (ROM)
- Traction Control
Seats
- 2-way adjustable front headrests (up/down)
- Driver's seat – 4-way with armrest
- Driver seatbelt warning light + sounds/belt mind
- Dual front passenger's seat – fixed back with lift-up seat cushion for stowage in outer seat
- Front 3 point seats (load limiters on outer seats/single seats,grabber on center seat on dual passenger)
- Front eatbelt pretensioner - driver_FMCSA
- Standard cloth seats
Steering
- Turning circle (kerb-to-kerb) (m) : 11.9
- Type: Rack & Pinion with rack-mounted power assisted
Steering Wheel
- Dual tone horn
- Steering column - 4-way adjustable (in/out/up/down)
- Steering wheel – 4-spoke, polyurethane
Suspension
- Front: Independent MacPherson struts, variable rate coil springs, stabiliser bar and gas pressurised shock absorbers
- Rear suspension: Single leaf springs, gas pressurised shock absorbers
Transmission
- Final Drive : 4.10
- Ratio's 1st : 5.441
- Ratio's 2nd : 2.839
- Ratio's 3rd : 1.721
- Ratio's 4th : 1.223
- Ratio's 5th : 1.000
- Ratio's 6th : 0.794
- Ratio's Rev : -4.935
- Type : 6-speed manual
Wheels & Tyres
- -
- Non-locking wheel nuts
- Spare wheel
- (Dual Rear Wheel) - 195/75 R16C 107/105 - Steel
- Hub caps
next
prev
Book A Test Drive
Stay Informed
Find Us
